RAD modell

THE AERIAL WORK PLATFORM

The RAD is a one seater with all the payload capability of a tandem ship, capable of carrying tons of equipment for research or commuting, while offering a great comfort to the pilot. Baggage or equipment  compartment is very wide and high, really best-in-class, and two additional external pods allow for even more space. This platform has been used successfully for aerial photography, photogrammetry, and for special radioactivity research programs.

WE ARE SOCIAL!

motorisation

  • Rotax  914 UL    Turbo   115 HP
  • Rotax  912 UL     turbo    120 HP

standard configuration

Carbon tail
Carbon booth
Tire trim
Pneumatic brakes
84 lt tank
Pneumatic rotor brake
Our extruded aluminum rotor of our production 8.50 mt
Elica duc wind spoon
Seat cover in waterproof fabric
Wide instrument dashboard for the pilot
Belts 4 points per pilot
Electrical system, prefabricated lighthouse and strobe and instrumentation

standard  instruments panel

Speed indicator
Variometer
Altimeter
Magnifoul pressure for turbo versions (914)
Pressure indicator and trimmer rotor brake
Rotor tachometer
Engine tachometer
Water temperature
Oil temperature
Oil pressure indicator
Fuel pressure index
Fuel level indicator
Radio and transponder predisposition

aditional equipment

metallic paint
Possibility to install tundra wheels
Self-healing cover
Propeller protection
Navigation lights and strobe lights
GPS Navigator
Radio Funkwerk ATR833
Transponder S TRT800

dati tecnici

ROTAX 914 UL Turbo & 912 Turbo
empty weight
278 kg
Maximum takeoff weight550 kg
Max speed - VNE168 km/h
speed cruiser150 km/h
minimum speed35 km/h
climb rate6 m/sec
Takeoff ride
100m
flight range350 km
